20' EU Container trailer 1:24

Post by truckmodell on Sun 14 Feb 2016, 9:30 pm

Hi




My new project is EU container trailer for 20' container. All parts I will make with CNC. I will use Tyres and mudguards from Italeri.
For drawing I'm using 3D programme. All parts I will make from Polystyrole. I decided that for this trailer I will do 2 chassis, namely one chassis will be designed for Italeri container which it doesn't have right measures, the second chassis will be for real container or tank container. 20' Italeri container has 25cm, the real 20' container has got 25,25cm.










truckmodell
AMCC NEWBIE!
AMCC NEWBIE!

Male Number of posts : 20
Age : 41
Location : Slovenia
Registration date : 2016-02-02

Back to top Go down

Re: 20' EU Container trailer 1:24

Post by truckmodell on Wed 17 Feb 2016, 7:34 am

Hi




A few pictures about making chassis:




















truckmodell
AMCC NEWBIE!
AMCC NEWBIE!

Male Number of posts : 20
Age : 41
Location : Slovenia
Registration date : 2016-02-02

Back to top Go down

Re: 20' EU Container trailer 1:24

Post by Antwon on Wed 17 Feb 2016, 10:24 pm

Interesting build so far.
avatar
Antwon
I Love this place
I Love this place

Male Number of posts : 888
Age : 51
Location : Adelaide SA
Registration date : 2013-02-10

Back to top Go down

Re: 20' EU Container trailer 1:24

Post by Jerry Ol'55 on Wed 17 Feb 2016, 11:35 pm

I'm asleep and dreaming???... this is not real???...This is Model building to the max!
avatar
Jerry Ol'55
I Love this place
I Love this place

Male Number of posts : 639
Age : 62
Location : Gosnells W.A.
Registration date : 2014-06-03

Back to top Go down

Re: 20' EU Container trailer 1:24

Post by truckmodell on Thu 18 Feb 2016, 8:03 am

Hi



Jerry OI'55 This is not a dream, this is really.



David

truckmodell
AMCC NEWBIE!
AMCC NEWBIE!

Male Number of posts : 20
Age : 41
Location : Slovenia
Registration date : 2016-02-02

Back to top Go down

Re: 20' EU Container trailer 1:24

Post by allan on Thu 18 Feb 2016, 8:32 am

WOW that some very cool work going into this one.
avatar
allan
AMCC ADDICT
AMCC ADDICT

Male Number of posts : 9544
Age : 60
Location : East Maitland
Registration date : 2008-03-31

Back to top Go down

Re: 20' EU Container trailer 1:24

Post by truckmodell on Fri 19 Feb 2016, 5:54 am

Hi





A few pictures about making chassis & airbags:
















truckmodell
AMCC NEWBIE!
AMCC NEWBIE!

Male Number of posts : 20
Age : 41
Location : Slovenia
Registration date : 2016-02-02

Back to top Go down

Re: 20' EU Container trailer 1:24

Post by truckmodell on Wed 24 Feb 2016, 4:50 am

Hi




I continue with work...








truckmodell
AMCC NEWBIE!
AMCC NEWBIE!

Male Number of posts : 20
Age : 41
Location : Slovenia
Registration date : 2016-02-02

Back to top Go down

Re: 20' EU Container trailer 1:24

Post by truckmodell on Sat 27 Feb 2016, 10:14 pm

Hi



Airbags for trailer:






















truckmodell
AMCC NEWBIE!
AMCC NEWBIE!

Male Number of posts : 20
Age : 41
Location : Slovenia
Registration date : 2016-02-02

Back to top Go down

Re: 20' EU Container trailer 1:24

Post by truckmodell on Fri 04 Mar 2016, 2:49 am

Hi




"SAF" suspension:
























truckmodell
AMCC NEWBIE!
AMCC NEWBIE!

Male Number of posts : 20
Age : 41
Location : Slovenia
Registration date : 2016-02-02

Back to top Go down

Re: 20' EU Container trailer 1:24

Post by truckmodell on Sun 06 Mar 2016, 5:48 pm

Hi



The shock absorbers:


















truckmodell
AMCC NEWBIE!
AMCC NEWBIE!

Male Number of posts : 20
Age : 41
Location : Slovenia
Registration date : 2016-02-02

Back to top Go down

Re: 20' EU Container trailer 1:24

Post by truckmodell on Sat 12 Mar 2016, 7:17 pm

Hi




Some pictures:








truckmodell
AMCC NEWBIE!
AMCC NEWBIE!

Male Number of posts : 20
Age : 41
Location : Slovenia
Registration date : 2016-02-02

Back to top Go down

Re: 20' EU Container trailer 1:24

Post by allan on Sun 13 Mar 2016, 9:16 am

WOW some cool work going into this one.
avatar
allan
AMCC ADDICT
AMCC ADDICT

Male Number of posts : 9544
Age : 60
Location : East Maitland
Registration date : 2008-03-31

Back to top Go down

Re: 20' EU Container trailer 1:24

Post by truckmodell on Sun 20 Mar 2016, 7:35 pm

Hi



Supporting leg for trailer:


































truckmodell
AMCC NEWBIE!
AMCC NEWBIE!

Male Number of posts : 20
Age : 41
Location : Slovenia
Registration date : 2016-02-02

Back to top Go down

Re: 20' EU Container trailer 1:24

Post by Antwon on Sun 20 Mar 2016, 9:25 pm

wow
Brilliant work Sir. This looks 100% professional.
Well done, and keep up the great work.
avatar
Antwon
I Love this place
I Love this place

Male Number of posts : 888
Age : 51
Location : Adelaide SA
Registration date : 2013-02-10

Back to top Go down

Re: 20' EU Container trailer 1:24

Post by truckmodell on Sun 27 Mar 2016, 8:45 am

Hi




Complete axis for trailer:




















































truckmodell
AMCC NEWBIE!
AMCC NEWBIE!

Male Number of posts : 20
Age : 41
Location : Slovenia
Registration date : 2016-02-02

Back to top Go down

Re: 20' EU Container trailer 1:24

Post by clea on Sun 27 Mar 2016, 2:06 pm

I do not wish to be derisive or belittling of anyone's endevours, however:
Truckmodell, your ability with manipulating Solidworks is admirable, the processing of sldpart files to a CNC machine is a everyday excercise for those in the manufacturing industry, particularly in Europe where Solidworks is the bigger brother to Autocad.
Component downloads are readily available from the D'assalt website. I have been associated with Solidworks, Autocad Designer and Catia for many years, in my other life.
The point I'm trying to make is this, the final output will either be for production runs of the model, or to show your dexterity in ..."Assembling Components".
I have enjoyed modelling as a hobby, for over 40 years, from glue bombs to where i think I am now, it has been a progression of learning and expanding my ability in a very satisfying manner.
I scratch build from dwgs, photos, measurements and notes or come up with iterative designs; always trying to better my ability.
Warts and all, and take pride in being able to say...."I built that!"
I admire and appreciate ALL of the posts on this site and the progression of peoples ability.

More deserved praise should be for the true modellers and their works on this site.
As i stated previously, I admire your dexterity with Solidworks.

Clea.
avatar
clea
I should be working on Models
I should be working on Models

Male Number of posts : 167
Age : 68
Location : portland victoria
Registration date : 2013-04-27

Back to top Go down

Re: 20' EU Container trailer 1:24

Post by truckmodell on Mon 28 Mar 2016, 5:52 am

Hi



Clea thank you for commendation. I draw with Solidworks and have CNC only 2 years.
If you master Solidworks we could collaborate. You could draw some Australian trailer which I could make it on CNC.  What do you say about this?



David

truckmodell
AMCC NEWBIE!
AMCC NEWBIE!

Male Number of posts : 20
Age : 41
Location : Slovenia
Registration date : 2016-02-02

Back to top Go down

Re: 20' EU Container trailer 1:24

Post by clea on Mon 28 Mar 2016, 8:58 am

David;
My "other life" is Mechanical Engineer, with programs as mentioned. My assumption is you either work in the design area of a trailer manufacturer, or have access to someone who does. As the sldpart's shown have to come from a assembly (1:1) of the systems, with the advent of A3 (desktop) CNC Engravers, it is then a fairly simple process to dump the file down at whatever scale you choose. I'm also assuming you maybe in the Dutch Modellers club, who presented this, or a similar model some years back.
Don't get me wrong David, I admire the replica, and look forward to seeing the completed item, along with the European version of the Drake trailer that is on the website.
I was only alluding to the fact that what you are currently showing is, (simply put) a Manufacturing process, and as a supplier could well be a very lucrative enterprise.
I have no problem with presenting yourself, or others with design drawings in any format that is applicable, I had toyed with the idea a while back when desktop plotters appeared, I have toyed with the purchase of a Scanner, and 3D printer.

I could sit and design trailers, or waste compactors, or tankers or whatever your predisposed to but the quandry then is do you go from a modeller to a manufacturer.

David, you are doing well; we shall talk further.

Cheers
Clea.
avatar
clea
I should be working on Models
I should be working on Models

Male Number of posts : 167
Age : 68
Location : portland victoria
Registration date : 2013-04-27

Back to top Go down

Re: 20' EU Container trailer 1:24

Post by Deaf as on Mon 28 Mar 2016, 8:00 pm

This is nice work, well done!
avatar
Deaf as
Legend Poster
Legend Poster

Male Number of posts : 1130
Age : 48
Location : Clergate
Registration date : 2013-11-20

Back to top Go down

Re: 20' EU Container trailer 1:24

Post by truckmodell on Tue 29 Mar 2016, 1:30 am

Hi



Clea I'm not a qualified civil engineer or technician but I am an electrician and manufactures 20 and 110kV power line.
I decided to buy a CNC because other manufacturers do not make any interesting designs, and this was the main reason, of course, is a consequence of this also that I had to learn 3D drawing and in this I was forced because of the CNC and now I have to admit that I am doing very well.

I'm not in the 'Dutch' club and the products that you will see is my work, it means that I first draw 3D model and then create with CNC, this means that I do prototyp.

I draw in such a way that first of all find the right trailer that could be interesting as a model of themselves and take nootebok. This means that the trailer draw and can solve problems that arise. In the end, everything is 100% copy original trailers.



David

truckmodell
AMCC NEWBIE!
AMCC NEWBIE!

Male Number of posts : 20
Age : 41
Location : Slovenia
Registration date : 2016-02-02

Back to top Go down

Re: 20' EU Container trailer 1:24

Post by clea on Tue 29 Mar 2016, 4:14 am

David,
You are doing extremely well, I will have a look and see what I can find, might be better to contact on a personal message.
What are the largest x,y,z parameters on the benchtop.

Clea.
avatar
clea
I should be working on Models
I should be working on Models

Male Number of posts : 167
Age : 68
Location : portland victoria
Registration date : 2013-04-27

Back to top Go down

Re: 20' EU Container trailer 1:24

Post by truckmodell on Wed 30 Mar 2016, 6:45 am

Hi



CNC - x=58cm, y=40cm, z=10cm
Polistyrol which I get in store has measures: x=50cm, y=25cm
I would do this trailer which you see on picture.





David

truckmodell
AMCC NEWBIE!
AMCC NEWBIE!

Male Number of posts : 20
Age : 41
Location : Slovenia
Registration date : 2016-02-02

Back to top Go down

Re: 20' EU Container trailer 1:24

Post by clea on Tue 05 Apr 2016, 4:47 pm

Hey David;
Happy Birthday..enjoy.

Clea.
avatar
clea
I should be working on Models
I should be working on Models

Male Number of posts : 167
Age : 68
Location : portland victoria
Registration date : 2013-04-27

Back to top Go down

Re: 20' EU Container trailer 1:24

Post by truckmodell on Sat 09 Apr 2016, 6:45 pm

Hi



Smile thank you!



David

truckmodell
AMCC NEWBIE!
AMCC NEWBIE!

Male Number of posts : 20
Age : 41
Location : Slovenia
Registration date : 2016-02-02

Back to top Go down

Re: 20' EU Container trailer 1:24
